Khush Sheets and Plates is a reputed manufacturer and supplier of top-grade Aluminium 3003 Plates and Sheets in Kolkata, India. With a strong emphasis on performance, durability, and customer satisfaction, we serve a broad category of industrial and commercial clients. Our Aluminium 3003 products are renowned for their superior corrosion resistance, formability, and smooth surface finish. We supply these sheets and plates in different thickness and sizes, so they are up to international standards. For roofing, insulation, or architecture needs, Khush Sheets and Plates provides dependable solutions according to your needs.
Aluminium 3003 contains mainly aluminium (circa 96.7–98.7%) and manganese (1.0–1.5%) as the prominent alloying component, with traces of copper, iron, and silicon. It presents good resistance to corrosion and fine workability. The strength of the alloy is typically in the range of 140–200 MPa for tensile and about 115 MPa for yield, with 10–20% elongation. Aluminium 3003 sheets and plates are non-heat-treatable but can be cold worked for increased strength, making them suitable for applications requiring moderate strength and excellent formability.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, we offer custom sizes for Aluminium 3003 Plates and Sheets to meet specific project needs. Our team at Khush Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.0517 | A93003 | AlCu4Mg | 3003 | AlCuMg2 |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
Aluminium 3003 Plates and Sheets are used extensively in applications that necessitate moderate strength and good corrosion resistance. They are used in roofing sheets, siding, insulation panels, storage tanks, and cookware. In the construction sector, they are a very good option for cladding and decorative purposes. On account of high formability, these sheets are best suited to produce ducts, garage doors, and vehicle panels. They are also used by food and chemical companies for storage containers and processing equipment. Their ease of welding and non-magnetic ability make them convenient to use in both domestic and industrial settings.
