ASTM A242 Corten Steel Sheets and Plates contain mostly iron and copper (0.25–0.55%), chromium (0.50–1.25%), nickel (0.65–1.25%), and trace amounts of phosphorus and manganese. These alloying constituents create an oxide protective film, with improved corrosion resistance. Some of its mechanical properties are a yield strength minimum of 345 MPa (50 ksi) and ultimate tensile strength of 485 MPa (70 ksi). The steel has good weldability and toughness, even at low temperatures. Its self-healing surface guarantees long life in aggressive environments, and thus is ideal for outdoor and industrial uses.
Grade : ASTM A242 Type 1 Corten Steel Plates
Standard : ASTM A242 / ASME SA242
Width : 750mm to 1500mm,
Length : 2500mm to 12000mm
Thickness : 0.8MM to 50mm
Type : Corten Steel / High-Strength Low-alloy Structural Steel
Process : Hot-Rolled (HR)
| Grade ASTM A242 TYPE 1 | C | Mn | Cr | Si | CEV | S | Cu | P |
| Max 0.12 | Max 1 | 0.3-1.25 | Max 0.75 | Max 0.52 | Max 0.03 | 0.25-0.55 | 0.06 – 0.15 |
Grade | Min. Yield Strength Mpa | Tensile Strength MPa | Impact | ||||||||
| A242 Type1 | Nominal Thickness (mm) | Nominal Thickness (mm) | degree | J | |||||||
| Thick mm | ≤16 | >16 ≤40 | >40 ≤63 | >63 ≤80 | >80 ≤100 | >100 ≤150 | ≤3 | >3 ≤100 | >100 ≤150 | -20 | 27 |
| A242 Type1 | 355 | 345 | …. | …. | …. | …. | 510-680 | 470-630 | …. | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Khush Sheets and Plates based in Kolkata, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
ASTM A242 Corten Steel Sheet and Plate offers several advantages, including exceptional resistance to corrosion and weathering, making it ideal for outdoor and architectural applications. Its self-healing patina forms over time, protecting the steel from further degradation. This steel also provides high strength, durability, and a distinctive rustic appearance, enhancing the aesthetic value of structures. Additionally, it requires minimal maintenance due to its ability to withstand harsh environmental conditions. Corten steel is also cost-effective in the long run, as it reduces the need for frequent coating or replacement.
Yes, we offer custom sizes for ASTM A242 Corten Steel Sheet and Plate to meet specific project needs. Our team at Khush Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@khushsheetsandplates.co.in
ASTM A242 Corten Steel Sheets and Plates are used across industries because of their weather-resistant properties and their attractive look. In architectural applications, they are used in building facades, roofing, cladding, and sculptures, where they can give a weathered look with less maintenance. In the transportation industry, they are used in railway cars, shipping containers, and truck frames. Structural uses involve outdoor structures, transmission towers, and bridges, where atmospheric corrosion resistance is crucial. Also, their long-term durability makes them appropriate for marine service and industrial equipment to provide long-lasting service at low cost.
