Khush Sheets and Plates is a well-known manufacturer and supplier of Carbon Steel C45 Sheet and Plates in Kolkata, India. We are expert in delivering high-quality C45 steel products renowned for their excellent strength, longevity, and accuracy. Our Carbon Steel C45 plates and sheets are extensively utilized in engineering and industrial use where moderate tensile strength and excellent machinability are required. Supported by state-of-the-art infrastructure, expert professionals, and rigorous quality checks, Khush Sheets and Plates provides ensured, cost-efficient solutions with guaranteed deliveries. We service various industries in India with optimized products designed for precise performance specifications.
Carbon Steel C45 Plates and Sheets have 0.42–0.50% carbon, 0.50–0.80% manganese, and trace amounts of silicon, phosphorus, and sulfur. The grade of medium carbon steel has good strength and hardness along with fair weldability. The material possesses tensile strength of approximately 570–700 MPa, yield strength of about 330 MPa, and elongation of approximately 16%. C45 steel has good machinability and can be heat treated through hardening and tempering to improve its wear resistance and mechanical properties for severe applications.
| Thickness | : | 2-600mm |
| Width | : | 4200-11000mm |
| Length | : | 3000-18000mm |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hairline, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, etc. |
| Grade | C | Mn | P | S | Cr | Si |
| C45 | 0.42-0.50 | 0.50-0.80 | 0.025 max | 0.025 max | 0.20-0.40 | 0.15-0.35 |
| Grade | Condition | Yield Strength R°(Mpa) | Tensile Strength Rm (Mpa) | Elon- gation A5(%) | Hardness HRC | Quenching Temperature (℃) | Benda- bility | Nominal Thickness,t 1.95mm≤t≤10.0mm | |
| Rolled | Annealed | ||||||||
| C45 | Rolled Annealed Water-quenched Oil quenched | 460 330 | 750 540 2270 1980 | 18 30 | 58 55 | 820 860 | Min.recommended Bending radius (≤90°) | 2.0 ×t | 1.0×t |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, we offer custom sizes for Carbon Steel C45 Sheet and Plates to meet specific project needs. Our team at Khush Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@khushsheetsandplates.co.in
Carbon Steel C45 Plates and Sheets find extensive application in the production of mechanical parts that need to have intermediate tensile strength and wear resistance. Some common applications are axles, shafts, gears, studs, crankshafts, and bolts. In heavy engineering, agriculture, and automotive industries, C45 steel plates are utilized to produce machine parts that are under moderate dynamic stresses. They find application in structural components, die blocks, tools, and base plates as well. Its excellent machinability and capacity for heat treatment render it ideal for the manufacture of precision parts and high-strength fittings in applications where toughness and size accuracy are requirements.
