Khush Sheets and Plates is a trusted manufacturer and supplier of Copper Nickel 90/10 Foil in Kolkata, India. We provide top-quality Cu-Ni 90/10 foils that exhibit superior corrosion resistance, particularly in saltwater and marine environments. We produce our foils with high-grade raw materials and superior production processes, which make them offer superior strength, thermal conductivity, and excellent durability. Used extensively in a wide range of industrial applications, our Copper Nickel 90/10 foils are in accordance with international standards and specifications. We at Khush Sheets and Plates are devoted to quality, accuracy, and customer satisfaction, providing timely supply and best possible price for all your industrial foil requirements.
Copper Nickel 90/10 Foil contains 90% copper and 10% nickel and traces of iron and manganese for greater strength and resistance to corrosion. It provides high mechanical stability and high thermal conductivity. The alloy has 310–350 MPa tensile strength, yield strength of about 90–130 MPa, and elongation of approximately 30%. It also exhibits good fabricability, weldability, and biofouling and seawater corrosion resistance. These characteristics make Cu-Ni 90/10 foil appropriate for demanding uses in marine, power generation, and chemical processing applications.
| Specifications | ASTM B122 |
| Dimensional specification | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 4mm-100mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Surface Finish | No.1, No.4, No.8 Mirror Finish, 2B |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cupro Nickel 90/10 | 88.6 min | 1.0 max | 0.05 max | 9-11 max | 1.8 max | 1 max |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cupro Nickel 90/10 | 88.6 min | 1.0 max | 0.05 max | 9-11 max | 1.8 max | 1 max |
| STANDARD | WERKSTOFF NR. | UNS |
| Cupro Nickel 90/10 | 2.0872 | C70600 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Copper Nickel 90/10 Foil is extensively utilized where there is high resistance to corrosion demanded, especially in marine and offshore environments. It is typically employed for ship hull cladding, seawater piping, and heat exchanger tube. In power generation and desalination facilities, it is utilized in evaporator and condenser systems. The foil is also used in the production of electronic components, electrical conductors, and battery connectors because of its superior thermal and electrical conductivity. Cu-Ni 90/10 foil is also suitable for application in chemical process plants and industrial uses where ductility, corrosion resistance, and durability are necessary.
