In Kolkata, India, Khush Sheets and Plates is a reputable producer and supplier of Duplex Steel S31803 Sheets and Plates. For a range of industrial applications, we provide premium duplex stainless steel products that combine exceptional strength and resistance to corrosion. The balanced austenitic-ferritic structure of S31803 is well-known for improving resistance to stress corrosion cracking, pitting, and crevice corrosion. Our sheets and plates are available in various sizes, thicknesses, and finishes to meet the diverse needs of sectors like chemical processing, oil & gas, marine, and construction. For each and every one of our customers, quality, dependability, and prompt delivery are our top priorities.
About 21–23% chromium, 4.5–6.5% nickel, 2.5–3.5% molybdenum, 0.08–0.20% nitrogen, and the remaining iron make up Duplex Steel S31803 Sheets and Plates. Manganese, silicon, and carbon are added in trace amounts. This alloy has an elongation of 25%, a yield strength of 450 MPa, and a tensile strength of about 620 MPa. Strength and resistance to corrosion are enhanced by its dual-phase microstructure. S31803 maintains outstanding mechanical and weldability qualities at low and moderately high temperatures, and it works well in environments that contain chloride.
| Size | : | 1/2″NB TO 4″NB IN |
| Standard | : | ASTM A182 / ASME SA182 |
| Dimensions | : | ANSI/ASME B16.11 & BS3799, etc. |
| Grade | : | UNS S31803, S32205, S2205, S32550, S32750, S32760. |
| Class | : | 2000LBS, 3000LBS, 6000LBS, 9000LBS, etc. |
| UNS S31803 | Ni | Cr | Mo | Mn | Si | C | N | S | P | Fe |
| min | 4.5 | 22.0 | 3.0 | – | – | – | 0.14 | – | – | – |
| max | 6.5 | 23.0 | 3.5 | 2.0 | 1.0 | 0.03 | 0.2 | 0.02 | 0.03 | Balance |
| Grade | S31803 |
| Density (g/cm 3) | 7.805 |
| Density (lb/in 3) | 0.285 |
| Melting Point (°C) | 1420 – 1465 |
| Melting Point (°F) | 2588 – 2669; |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Duplex 2205 | UNS S31803 | 1.4462 | F51 |
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Because of their exceptional resistance to corrosion caused by chloride stress, Duplex Steel S31803 Sheets and Plates are frequently utilised in chemical processing, desalination facilities, and offshore oil and gas platforms. They are used in the marine industry for seawater piping systems, propeller shafts, and shipbuilding. The food processing and pharmaceutical industries value S31803’s hygienic qualities, while the pulp and paper industry uses it for digesters and liquor tanks. These plates and sheets are also used in storage tanks, pressure vessels, and heat exchangers where high strength and resistance to corrosion are necessary.
