Khush Sheets and Plates is a reliable manufacturer and supplier of High Carbon Steel Plates in Kolkata, India, catering to a variety of industries with high-quality steel solutions. Our high carbon steel plates are renowned for their superior hardness, strength, and durability, and hence preferred for challenging industrial applications. We exercise strict quality control procedures and adopt state-of-the-art processing methods to provide plates that satisfy national and international standards. With customer satisfaction, prompt delivery, and competitive pricing in mind, Khush Sheets and Plates has developed a robust image in the business of steel manufacturing and supply.
High Carbon Steel Plates have a carbon content ranging from 0.60% to 1.00%, with minor amounts of manganese (0.30–0.90%), silicon, sulfur, and phosphorus. This makes the material harder and stronger, but less ductile and very wear-resistant. Its tensile strength is between 700 and 950 MPa, and the yield strength is usually approximately 500 MPa, which depends on heat treatment. These plates have good abrasion and deformation resistance but lower weldability than low and medium carbon steels. Their mechanical performance is improved by heat treatment like quenching and tempering.
Standard : ASTM A830/ASME SA830
Thickness : 2mm – 600mm
Width : 1000mm – 3000mm
Length : 3000mm – 12000mm
| Grade | C(%)min-max | Si(%)min-max | Mn(%)min-max | P(%)max | S(%)max | Cr(%)min-max |
| C45 | 0.42-0.50 | 0.15-0.35 | 0.50-0.80 | 0.025 | 0.025 | 0.20-0.40 |
| Grade | Condition | Yield Strengtd R°(Mpa) | Tensile Strength Rm (Mpa) | Elon- gation A5(%) | Hardness HRC | Quenching Temperature (℃) | Benda- bility | Nominal Thickness,t 1.95mm≤t≤10.0mm | |
| Rolled | Annealed | ||||||||
| C45 | Rolled Annealed Water-quenched Oil quenched | 460 330 | 750 540 2270 1980 | 18 30 | 58 55 | 820 860 | Min.reco-mmended Bending radius (≤90°) | 2.0 ×t | 1.0×t |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, we offer custom sizes for High Carbon Steel Sheet and Plates to meet specific project needs. Our team at Khush Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@khushsheetsandplates.co.in
| C45 EN 10083-2 Number:1.0503 | Comparison of steel grades | |
| JIS G 4051 | S 45 C | |
| DIN 17200 | C 45 | |
| NFA 33-101 | AF65-C 45 | |
| UNI 7846 | C 45 | |
| BS 970 | 070 M 46 | |
| UNE 36011 | C 45 k | |
| SAE J 403-AISI | 1042/1045 | |
High Carbon Steel Plates are extensively used in applications that involve higher strength, hardness, and resistance to wear. They are generally applied in the production of cutting tools, blades, industrial knives, springs, and dies. In the heavy machinery and construction industries, these plates are utilized in wear-resistant liners, mining machinery, and structural components exposed to high stress. They are applied by automotive industries in engine components, gears, and axles. Their excellent durability also makes them appropriate for agricultural equipment, railroads, and military parts. Even though they have lower weldability, their machinability and high load bearing capability make them invaluable in high-stress applications.
