In Kolkata, India, Khush Sheets and Plates is a well-known producer and supplier of Incoloy 800 Foils. For exceptional resistance to oxidation, carburisation, and high-temperature corrosion, we provide high-performance nickel-iron-chromium alloy foils. Our Incoloy 800 foils are extensively utilised in the chemical, thermal processing, and power generation industries and are designed to satisfy international standards. At Khush Sheets and Plates, we prioritise accurate production, personalised sizing, and prompt delivery to satisfy the demanding needs of customers in India and abroad. Our products are renowned for their performance in the most demanding environments, strength, and dependability.
Nickel (30–35%), iron (39.5% min), and chromium (19–23%) make up the majority of Incoloy 800 Foils, with trace amounts of aluminium, titanium, carbon, and manganese. With a tensile strength of 500–600 MPa, yield strength of approximately 200–275 MPa, and elongation of 30–45%, these foils provide exceptional mechanical strength. Up to 1100°C, Incoloy 800 retains its structural integrity and oxidation resistance. The alloy is perfect for foil applications under high pressure and heat because of its metallurgical stability and stress rupture characteristics.
Specifications : ASTM / ASME SB 409
Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
Grade : Incoloy Alloy 800 (UNS No. N08800) Coils & Strips
Hardness : Soft, Hard, Half Hard, Spring Hard, etc.
Finish : Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated)
Other services : Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | GOST | OR | BS | JIS | EN |
| Incoloy 800 | N08800 | 1.4876 | Z8NC32-21 | ЭИ670 | XH32T | NA 15 | NCF 800 | X10NiCrAlTi32-20 |
| Incoloy 800 | C | Cr | Fe | S | Ni | Mn | Si | Cu |
| 0.10 max | 19.00 – 23.00 | 39.50 min | 0.015 max | 30.00 – 35.00 | 1.50 max | 1.00 max | 0.75 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Khush Sheets and Plates based in Kolkata, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Incoloy 800 Foils offer exceptional advantages, making them ideal for demanding industrial applications. Their high-temperature strength ensures reliable performance in extreme environments, while excellent oxidation and carburization resistance prolongs service life. The alloy’s superior corrosion resistance in acidic and oxidizing conditions adds to its versatility. Incoloy 800 foils maintain mechanical stability under thermal cycling, reducing deformation risks. Their ease of fabrication and welding supports diverse manufacturing needs. Commonly used in heat exchangers, petrochemical equipment, and nuclear power plants, these foils are a trusted choice for durability and operational efficiency.
| Size (mm) | Weight per (Kg) | Size (mm) | Weight per (Kg) |
|---|---|---|---|
| 2000 x 1000 x 2.0 | 32.7 | 2000 x1000 x 0.9 | 14.7 |
| 3000 x 1500 x 1.5 | 55.3 | 2500 x1250 x 0.7 | 17.9 |
| 3000 x 1500 x 2.0 | 73.7 | 2000 x1000 x 1.0 | 16.4 |
| 2500 x 1250 x 1.5 | 38.4 | 2000 x1000 x 0.7 | 11.5 |
| 3000 x 1500 x 3.0 | 112.0 | 2000 x1000 x 1.5 | 24.6 |
| 2500 x 1250 x 2.0 | 51.2 | 2500 x1250 x 0.9 | 23.0 |
| 2000 x 1000 x 2.5 | 40.9 | 2500 x1250 x 1.0 | 25.6 |
| 2500 x 1250 x 2.5 | 63.9 | 3000 x1500 x 1.0 | 36.8 |
| 2500 x 1250 x 3.0 | 77.5 | 3000 x1500 x 1.2 | 44.2 |
| 3000 x 1500 x 2.5 | 92.1 | 2000 x1000 x 1.2 | 19.6 |
| 2000 x 1000 x 3.0 | 49.6 | 2500 x1250 x 1.2 | 30.7 |
Yes, we offer custom sizes for Incoloy 800 Foils to meet specific project needs. Our team at Khush Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Incoloy 800 Foils are widely used in the petrochemical processing, heat treatment, and power generation sectors where oxidation resistance and high temperature strength are essential. They are frequently used in high-temperature seals, exhaust linings, thermal shields, and furnace insulation. Incoloy 800 Foils are also utilised in chemical reactors, piping systems that handle steam or hot corrosive gases, and superheater and reheater tubing. They are perfect for gasket manufacturing, expansion joints, and insulation wraps in settings where they are constantly exposed to high temperatures and corrosive substances because of their thin, flexible nature and exceptional mechanical integrity.
