Based in Kolkata, India, Khush Sheets and Plates is a reputable producer and supplier of Jethete M152 Sheets and Plates. The business provides premium Jethete M152 products that satisfy the exacting requirements of the power generation, aerospace, and high-performance engineering industries with a dedication to quality and accuracy. Khush Sheets and Plates, which is well-known for providing materials with exceptional strength and heat resistance, guarantees that its products are produced in accordance with international standards. With state-of-the-art facilities and expert technical support, the company provides customized solutions and timely delivery, earning the trust of clients across India and global markets for Jethete-grade materials.
The main component of Jethete M152, a high-strength, martensitic stainless steel alloy, is chromium (about 12%), with nickel, molybdenum, and vanadium added for improved performance. Particularly after heat treatment, it provides good fracture toughness, high tensile strength (up to 1240 MPa), and exceptional creep resistance. The alloy is appropriate for stress-loaded components because it retains its mechanical integrity at high temperatures (up to 560°C). It is a sensible option for intricate, high-stress applications due to its weldability and machinability, while its exceptional hardness and resistance to corrosion make it perfect for harsh environments.
| Standard Specification : | ASTM A666 / ASME SA666, Jethete M152 (BS S151/ S159) | MSRR 6503 | AMS 5719 | DTD 5066 | WS 1.4933 | AECMA FE-PM37 | UNS S64152 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| STANDARD | UNS | WERKSTOFF NR. | BS | MSRR | AMS | DTD | AECMA |
| Jethete M152 | S64152 | 1.4933 | S151/ S159 | 6503 | 5719 | 5066 | FE-PM37 |
| C | Si | Mn | P+S max | Cr | Mo | Ni | N | V |
| 0.08-0.13 | 0.35 max | 0.50-0.90 | P 0.030 S 0.025 | 11-12.5 | 1.50-2.0 | 2-3 | 0.02-0.04 | 0.25-0.40 |
| Grade | Treatment | Tensile Strength Mpa | Yield Strength Mpa | Elongation % | Hardness HB | Ruling Section |
| S151A S151D | Softened Finally Heat Treated | 930-1130 | 780 | 14 | 311max 286-311 | – 150mm |
| S159A S159D | Softened Finally Heat Treated | 1100-1300 | 900 | 8 | 311 max 321-388 | 50mm |
| AMS 5719 AMS 5719 | Annealed Hardened & Double Templerd | 1069 min | 896 | 12 | 311 341-375 | – – |
| Physical Properties | Imperial | Metric |
| Density | 0.28 lb/in³ | 7.75 g/cc |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Khush Sheets and Plates based in Kolkata, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Yes, we offer custom sizes for Jethete M152 Sheets and Plates to meet specific project needs. Our team at Khush Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@khushsheetsandplates.co.in
High-performance mechanical systems, nuclear power systems, turbine engine parts, and aerospace all make extensive use of Jethete M152 Sheets and Plates. They are perfect for turbine blades, jet engine components, shafts, and fasteners because of their capacity to function under harsh temperature and stress conditions. Because of their long-term durability and creep resistance, they are utilised in nuclear reactor components and steam turbines in the energy sector. Furthermore, the alloy is useful in high-pressure settings, precision tooling, and structural components due to its exceptional mechanical and thermal qualities, which guarantee performance, safety, and dependability in the most demanding industrial settings.
