Khush Sheets and Plates is a leading Kovar Sheets and Plates manufacturer and supplier in Kolkata, India. We have expertise in delivering engineered metal solutions addressing the specialized needs of high-reliability sectors. Our Kovar Sheets and Plates are engineered to provide superior thermal expansion compatibility with ceramics and glass, making them suitable for hermetic sealing applications. Supported by sophisticated infrastructure and stringent quality control, we make sure our products meet international standards. With precision, reliability, and timely delivery as our focus, Khush Sheets and Plates is your reliable provider of high-grade Kovar alloy products in India.
Kovar Sheets and Plates consist of nearly 29% nickel, 17% cobalt, and the rest iron, together with trace amounts such as manganese and silicon. Such a special composition provides Kovar with thermal expansion matching that of borosilicate glass. Kovar alloy has high mechanical strength with tensile strength of about 517 MPa, yield strength of nearly 414 MPa, and good ductility. Kovar is stable in temperature-sensitive applications and has a density of about 8.36 g/cm³. Due to these characteristics, it is suitable for glass-to-metal and ceramic-to-metal sealing applications in challenging environments.
| Standard Specification : | UNS K94610 | Werkstoff Nr 1.3981 | DIN 17745 | ASTM F15 | AMS 7726 | AFNOR NF A54-301 | S.E.W 385 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Chemical Analysis | |
| Cr | 20 nom |
| Ni | 35 nom |
| Mo | 10 nom |
| Co | 35 nom |
| Material | Condition | Yield Strength (0.1% Offset) | Tensile Strength | Elongation % | ||
|---|---|---|---|---|---|---|
| psi | MPa | psi | MPa | |||
| Alloy K Kovar | Annealed | 49,000 | 340 | 75,000 | 520 | 42 |
| ASTM | UNS | Workstoff | AMS | DIN | AFNOR | S.E.W |
| F15 | K94610 | 1.3981 | 7726 | 17745 | NF A54-301 | 385 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kovar Plates and Sheets are widely used in applications that demand a close thermal expansion match with glass or ceramics. The alloy is extensively used in the electronics industry for the production of hermetic seals in devices like transistors, diodes, integrated circuits, and vacuum tubes. In aerospace and defense, Kovar is utilized in high-reliability electronic packages and instrumentation. It is also used in medical devices, scientific instruments, and optical devices where there is a need for dimensional stability through temperature changes. Kovar’s capability to provide a hermetic seal makes it crucial for parts undergoing thermal cycling and high-vacuum applications.
