Khush Sheets and Plates is a renowned Kolkata, India-based manufacturer and supplier of superior quality Nickel Alloy 200 Angles. These are made with high standards of quality and durability to handle the stringent requirements of different industries. Khush Sheets and Plates lays strong emphasis on precision, reliability, and timely delivery while assuring each product to match high global standards. Our dedication to product quality and customer satisfaction has established us as a top pick among clients in India and internationally.
Nickel Alloy 200 is primarily composed of more than 99% nickel along with trace amounts of iron, carbon, and manganese. The formula gives an extraordinary resistance to corrosion, particularly in environments that are reducing in nature. The alloy contains tensile strength of around 550 MPa and yield strength approximately 210 MPa. It provides good ductility with elongation of approximately 40% and a Brinell hardness of 90 to 150. Due to its superior thermal conductivity and resistance to mechanical stability at high temperatures, it finds application in challenging uses.
Specifications : ASTM B160 / ASME SB160
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 200 Angle offers excellent corrosion resistance, particularly against alkaline solutions, fresh water, and organic acids. Its high strength and durability make it ideal for harsh industrial environments, including chemical processing, marine, and aerospace applications. The alloy maintains its mechanical properties at elevated temperatures and resists oxidation, ensuring long-lasting performance. It also provides excellent weldability and formability, making fabricating various shapes easy. Its non-magnetic properties enhance its versatility in electronics and other precision applications, offering reliable performance in demanding conditions.
Nickel Alloy 200 Angles find extensive applications in chemical processing, aerospace, marine, and electrical applications due to their superior corrosion resistance and strength. They find their application in the production of heat exchangers, chemical tanks, and valves that serve under extreme conditions. Their resistance to both cryogenic and high temperatures finds them of use in aerospace equipment and power generation plant equipment. They are also widely used in structural supports and frameworks where strength and acid as well as oxidation resistance is needed.
