Khush Sheets and Plates is a prominent manufacturer and supplier of Nickel Alloy 201 Sheets and Plates from Kolkata, India. Having years of industry experience, we offer high-quality products renowned for their great durability, resistance to corrosion, and good performance in challenging conditions. Our sophisticated manufacturing processes and high-quality control guarantee that each sheet and plate conforms to international standards. Serving different industries such as chemical processing, power generation, and marine, Khush Sheets and Plates is dedicated to offering excellence, reliability, and customer satisfaction within India and the international market.
Nickel Alloy 201 Sheets and Plates are mainly made up of 99.6% Nickel, with trace elements of Iron (≤0.4%), Manganese (≤0.35%), Copper (≤0.25%), and Silicon (≤0.35%). This low-carbon grade provides excellent caustic alkali and reducing chemicals resistance. Mechanical properties are tensile strength of 377 MPa (55 ksi), yield strength (0.2% offset) of 103 MPa (15 ksi), elongation of ≥50%, and Rockwell maximum hardness of B80. The alloy exhibits excellent mechanical properties at both high and cryogenic temperatures.
| Grade | Nickel Alloy 201 | UNS N02201 |
| Standard | ASTM B162 / ASME SB162 |
| Size | 1000 mm x 2010 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2010 mm x 2010 mm, 2010 mm x 4000 mm |
| Thickness | 0.1mm To 100 mm |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Plain Sheet, Shim Sheet, Strip, Flats |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 201 Sheets and Plates offer excellent corrosion resistance, particularly in acidic and alkaline environments. They are highly resistant to oxidation and possess superior thermal and electrical conductivity. These alloys are known for their excellent formability, allowing easy shaping and welding. With outstanding mechanical properties at high and low temperatures, Nickel Alloy 201 is ideal for chemical processing, heat exchangers, and electronics applications. It also provides strength and stability, making it suitable for harsh environments and high-stress applications.
|
Nickel 201 plate Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.134″ |
3.40 |
|
.125″ |
3.18 |
|
.187″ |
4.75 |
|
.156″ |
3.96 |
|
.312″ |
7.92 |
|
.250″ |
6.35 |
|
.500″ |
12.7 |
|
.375″ |
9.53 |
|
.600″ |
15.9 |
|
.875″ |
22.2 |
|
.750″ |
19.1 |
|
1″ |
25.4 |
|
3″ |
76.2 |
|
1.250″ |
31.8 |
|
1.125″ |
28.6 |
|
1.500″ |
38.1 |
|
2″ |
50.8 |
|
1.750″ |
44.5 |
|
2.500″ |
63.5 |
Nickel Alloy 201 Sheets and Plates are extremely versatile and have vast applications in various industries. They are widely applied to the chemical processing industry in caustic soda and other alkalis handling. In the electronics industry, they are applied in battery parts and electric contacts because of their good thermal and electrical conductivity. In food processing and pharmaceutical machinery, they provide corrosion-free processes. The alloy finds the marine and aerospace parts suitable that need superior strength and resistance to oxidation. It is also utilized in pressure vessels, heat exchangers, and piping systems where reliability and performance are essential.
