Khush Sheets and Plates is a well-known supplier and manufacturer of S355JR+N Plates and Sheets in Kolkata, India. We provide high-strength structural steel plates with excellent weldability and toughness. Our S355JR+N plates are normalized according to EN 10025 standards and are ideal for various engineering and construction purposes. At Khush Sheets and Plates, we specialize in delivering accurate sizes, higher surface finish, and on-time delivery. Backed by a customer-driven strategy and strong infrastructure, we service industries all over India with dependable and economic steel plate solutions.
S355JR+N Plates and Sheets are structural low-alloy steels of typical composition: carbon (≤0.24%), manganese (1.0–1.6%), silicon (≤0.55%), phosphorus (≤0.035%), and sulfur (≤0.035%). The “+N” signifies that the plates are normalized for better toughness. The material possesses a minimum yield strength of 355 MPa and tensile strength between 470–630 MPa. It provides satisfactory impact resistance at room temperature and good weldability. S355JR+N offers a compromise between strength and ductility and is thus applicable for use in fabrication and structural application under dynamic and fluctuating environmental loadings.
Item : S355JR+N – Offshore & Structural Steel Plate
Thickness : 5mm-150mm
Width : 1000mm-4500mm
Length : 3000mm-18000mm or as custom’s request
Material : En 10025-2 Steel Plate, S355JR+N Steel Plate
Technique : hot rolled
Standard : EN 10025-2:2004
| Grade | C | Mn | Si | P | S | N | Cu | CEV |
| S355JR+N | 0.24 max. | 1.6 max. | 0.55 max. | 0.04 max. | 0.04 max. | 0.012 max. | 0.55 max. | 0.47 max. |
| Grade | Thickness (mm) | Min Yield (Mpa) | Tensile (Mpa) | Elongation (%) | Min Impact Energy | |
| S355JR+N | 8mm-100mm | 315-355 Mpa | 450-630 Mpa | 18-20% | 20 | 27J |
| 101mm-200mm | 285-295 Mpa | 450-600 Mpa | 18% | 20 | 27J | |
| 201mm-400mm | 275 Mpa | – | 17% | 20 | 27J | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, we offer custom sizes for S355jr+n Sheet and Plates to meet specific project needs. Our team at Khush Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@khushsheetsandplates.co.in
S355JR+N Plates and Sheets are used extensively in engineering and structural applications where toughness and high strength are necessary. They are used in construction of buildings, bridges, transmission towers, and offshore platforms. They are also utilized for making heavy machinery parts, equipment, crane booms, and pressure vessels. The plates have excellent machinability and weldability, which makes them a good choice for both bolted and welded constructions. In transportation applications, S355JR+N plates are employed for use in chassis, frames, and truck bodies. Their dynamic load performance and fatigue and impact resistance enhance their selection in contemporary structural steel design.
