Khush Sheets and Plates is a prominent producer and exporter of S690QL Steel Sheets and Plates in Kolkata, India. We are experts in providing high-strength, low-alloy steel plates for critical engineering and load-carrying applications. Our S690QL Sheets and Plates are renowned for superior toughness, weld ability, and very good strength-to-weight ratio, which is appropriate for heavy-duty industrial applications. We manufacture them with the latest technology and according to international quality standards and supply them to industries like construction, mining, and heavy machinery. Khush Sheets and Plates provides fast service, competitive rates, and quality in all orders.
S690QL Steel Plates and Sheets are quenched and tempered structural steels with high strength having a general composition of carbon (≤0.2%), manganese, chromium, molybdenum, and nickel and proving superior hardenability and toughness. The plates provide a minimum yield point of 690 MPa and tensile strength of 770–940 MPa. The plates have very good impact properties even at sub-zero temperatures (tested at -40°C) and have good weldability with minimum preheating requirements. S690QL has a fine grain structure and provides good fatigue resistance and can be used where strength along with lower structural weight is required.
Thickness : 5MM & Above
Width : 1500 – 3500mm
Length : 3000 – 18000mm
Grade : S690QL EN10137-2 EN10025-6:2004, A709-100, DILLIMAX 690, NAXTRA 70, WELDOX 700, E690, JFE HITEN 780LE, ALFORM 700
|
Percentage % |
Element |
Percentage % |
Element |
|
0.050 |
Cu |
0.020 |
C |
|
0.070 |
Mo |
0.080 |
Si |
|
0.006 |
Nb* |
1.070 |
Mn |
|
2.00 |
Ni |
0.0025 |
P |
|
0.005 |
Ti* |
0.0015 |
S |
|
0.012 |
V* |
0.0015 |
N |
|
0.015 |
Zr* |
0.00050 |
B |
|
1.050 |
Cr |
| Plate Thickness | Yield Strength | Tensile Strength | Elongation | Impact Strength |
| MM | ReH (MPa) | Rm (MPa) | A5 % Minimum | J, Minimum |
| 3 to 50 | 690 | 770 – 940 | 14 | 30 @ -40º C |
| > 50 to 100 | 650 | 760 – 930 | 14 | 30 @ -40º C |
| > 100 to 150 | 630 | 710 – 900 | 14 | 30 @ -40º C |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, we offer custom sizes for S690ql Steel Sheet and Plates to meet specific project needs. Our team at Khush Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@khushsheetsandplates.co.in
S690QL Steel Plates and Sheets are used extensively in industries where high-strength and light-optimized structural material is needed. In building construction, it is employed for bridges, cranes, and load-carrying structures. Mining and earthmoving equipment industries use such plates for chassis, bucket, and support arm applications because of their great wear and impact resistance. In the energy industry, they find application in wind tower elements and offshore platforms. S690QL is also employed on transport vehicles such as trailers and containers where strength is high and weight is minimal. Its superior performance under stress makes it the best choice for robust, high-loading applications in harsh environments.
