Based in Kolkata, India, Khush Sheets and Plates is a top producer and supplier of stainless steel 253MA sheets and plates. We offer premium SS 253MA products to satisfy the exacting requirements of industries both domestically and internationally. We are well-known for providing materials that are resistant to oxidation and high temperatures. Our 253MA sheets and plates are perfect for heat-intensive applications because they are engineered to have exceptional strength and durability at high temperatures. Delivering dependable stainless steel solutions that satisfy global standards and guarantee long-term performance is Khush Sheets and Plates’ top priority.
Chromium (20–22%), Nickel (10–12%), Silicon (~1.4–2%), and rare earth metals for improved oxidation resistance are all present in stainless steel 253MA, a high-temperature austenitic alloy. Nitrogen is also added for greater creep strength. The alloy has an elongation of about 40%, a yield strength of 310 MPa, and a minimum tensile strength of about 600 MPa. Because of its exceptional performance at temperatures as high as 1150°C and its special combination of high-temperature strength, oxidation resistance, and structural stability, SS 253MA is perfect for high-temperature settings and extended thermal exposure.
| Grade | 253 MA| UNS S30815 |
| Standard | ASTM A240 / ASME SA240 |
| Thickness | 0.1mm To 100 mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Coils, Slatting Coils, Perforated Coils |
| Applications | Off-Shore Oil Drilling Companies, Power Generation, Petrochemicals, Gas Processing, Specialty Chemicals, Pharmaceuticals, Pharmaceutical Equipment, Chemical Equipment, Sea Water Equipment, Heat Exchangers, Condensers, Pulp and Paper Industry |
| Grade | C | Mn | Si | S | Ce | Ni | Cr | P |
| 253 MA | 0.05 – 0.10 | 0.80 max | 1.40 – 2 | 0.030 max | 0.03 – 0.08 | 10 – 12 | 20 – 22 | 0.040 max |
| Density | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.8 g/cm3 | MPa -600 | MPa – 310 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
DIN 1.4835 Sheets and Plates offer outstanding advantages, including exceptional oxidation resistance up to 1150°C, making them ideal for high-temperature applications. Their balanced composition enhances creep resistance and ensures durability under thermal cycling. The addition of silicon and nitrogen improves strength and ductility, while cerium boosts stability in oxidizing environments. These sheets are easy to fabricate and weld, reducing production challenges. With superior corrosion resistance and excellent mechanical properties, they are highly suitable for applications in petrochemical plants, heat exchangers, and furnace components, ensuring reliability and long service life.
| Surface finish | Thickness (in) | Width (in) |
|---|---|---|
| 1 – Stainless Steel 253 MA Hot rolled, heat treated, pickled Plate & Sheet | .1000 – .3750 | max. 72 |
| 2R – Stainless Steel 253 MA Cold-rolled, bright-annealed Sheet & Plate | 0.002–0.06 | 0.118–25.551 |
| 2H – Stainless Steel 253 MA Work hardened Plate & Sheet | 0.002–0.06 | 0.118–24.803 |
| 2B – Stainless Steel 253 MA Cold rolled, heat treated, pickled, skin passed Sheet & Plate | 10–24 | max. 72* |
| 2D – Stainless Steel 253 MA Cold rolled, heat treated, pickled Plate & Sheet | 12–24 | max. 60 |
| BA Mexinox only | 18–28 | max. 48 |
| Deco Rolled-On Mexinox only | 14–28 | max. 48 |
| Stainless Steel 253 MA Polished Plate & Sheet (not brushed) | 11–24 | max. 60 |
| Temper rolled Mexinox only | 13–29 | max. 48 |
| STANDARD | WERKSTOFF NR. | UNS | SS | EN |
| 253 MA | 1.4835 | S30815 | 2368 | X9CrNiSiNCe21-11-2 |
| Material | Size | Thickness |
|---|---|---|
| PLATES / SHEETS / COILS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
Because of its exceptional resistance to oxidation and creep, stainless steel 253MA Sheets and Plates are frequently utilised in high-temperature applications. For parts like furnace parts, radiant tubes, heat exchangers, and burner nozzles, 253MA is essential to industries like heat treatment, cement production, power generation, and metallurgy. It is appropriate for kilns, combustion chambers, and petrochemical processing facilities due to its exceptional performance in oxidising and reducing environments. Additionally, SS 253MA is used in catalytic converter systems and refinery heaters. It is an excellent option for demanding, high-heat industrial operations due to its mechanical stability, resistance to thermal fatigue, and extended service life.
