Delivering premium heat-resistant stainless steel solutions for industrial and structural applications, Khush Sheets and Plates is a reputable manufacturer and supplier of Stainless Steel 310H Sheets and Plates in Kolkata, India. A high-carbon variant of grade 310 stainless steel, 310H is intended for use at higher temperatures. To guarantee dimensional accuracy and durability, we use high-quality raw materials and sophisticated processing techniques in the manufacturing of our sheets and plates. Khush Sheets and Plates serves industries requiring dependable, high-temperature stainless steel products with exceptional service life by being widely used in furnace parts, heat treatment equipment and thermal processing units.
The main components of stainless steel 310H sheets and plates are 25% chromium, 20% nickel, and a higher carbon content (~0.04–0.10%) than regular 310 grade, which improves high-temperature strength. Manganese, silicon, phosphorus, and sulphur are additional elements. This alloy has an elongation of about 40%, a yield strength of 205 MPa, and a tensile strength of 515 MPa. Up to 1100°C, it maintains its strength and resistance to oxidation. It is appropriate for extended exposure to high temperatures and harsh thermal environments due to its high carbon content, which enhances creep resistance.
| Specifications | ASTM A240 / ASME SA240 |
|---|---|
| Width | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Length | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 310H | min. | 0.04 | – | – | – | – | 24.0 | – | 19.0 | – |
| max. | 0.10 | 2.0 | 1.00 | 0.045 | 0.03 | 26.0 | 21.0 | – | ||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 310H | 515 | 205 | 40 | 95 | 217 |
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 310H | S31009 | – | – | – | – | – | – |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| 2000MM X 1000MM X 3MM | 2000MM X 1000MM X 6MM |
| 2500MM X 1250MM X 4MM | 2500MM X 1250MM X 8MM |
| 3000MM X 1500MM X 3MM | 3000MM X 1500MM X 6MM |
| 3000MM X 1500MM X 4MM | 3000MM X 1500MM X 8MM |
| 2000MM X 1000MM X 5MM | 2500MM X 1250MM X 10MM |
| 2500MM X 1250MM X 3MM | 2500MM X 1250MM X 6MM |
| 4000MM X 2000MM X 3MM | 4000MM X 2000MM X 6MM |
| 2500MM X 1250MM X 5MM | 3000MM X 1500MM X 10MM |
| 2000MM X 1000MM X 4MM | 2000MM X 1000MM X 8MM |
| 4000MM X 2000MM X 4MM | 2000MM X 2000MM X 10MM |
| 3000MM X 1500MM X 5MM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
High-temperature industrial applications frequently use stainless steel 310H sheets and plates, particularly when increased creep resistance is needed. They are used in boiler parts, kiln linings, heat exchangers, and furnace components in the thermal processing and heat treatment industries. They are utilised in the chemical and petrochemical industries for thermal crackers, radiant coils, and reformer tubes. They are also perfect for combustion chambers, waste heat recovery systems, and incinerators. For long-term durability and structural integrity, they are appropriate for harsh thermal and oxidising environments due to their exceptional resistance to oxidation and carburisation at high temperatures.
