Based in Kolkata, India, Khush Sheets and Plates is a top producer and supplier of stainless steel 347 angles. We are renowned for providing structural products made of high-performance stainless steel that are suited for demanding industrial applications. Because of its resistance to intergranular corrosion, Stainless Steel 347, a stabilised austenitic stainless steel alloy, is perfect for high-temperature applications. Khush Sheets and Plates provides SS 347 Angles that are strong, durable, and weldable to international standards. We cater to industries like aerospace, petrochemicals, power generation, and fabrication with a robust supply network, a customer-first philosophy, and prompt delivery.
17–20% chromium, 9–13% nickel, and columbium (niobium) are added to stainless steel 347 to stabilise it against intergranular corrosion. It also contains silicon, manganese, and a small amount of carbon (up to 0.08%). With good ductility and elongation (~40%), SS 347 has a yield strength of about 205 MPa and a tensile strength of roughly 515–750 MPa. The alloy has outstanding resistance to oxidation and retains strength at high temperatures. It is appropriate for demanding operating environments because it is non-magnetic when annealed and maintains its toughness even in cryogenic settings.
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 347 Angle | 5mm to 9mm |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | SS 347 |
|---|---|
| C | 0.08 max |
| Mn | 2 max |
| Si | 1 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 17 – 20 |
| Cb | 10xC – 1.10 |
| Ni | 9.0 – 13.0 |
| Fe | 62.74 min |
| Grade | SS 347 |
|---|---|
| Density | 8.0 g/cm3 |
| Melting Point | 1454 °C (2650 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35% |
| STANDARD | SS 347 |
| WERKSTOFF NR. | 1.4550 |
| UNS | S34700 |
| JIS | SUS 347 |
| BS | – |
| GOST | 08Ch18N12B |
| AFNOR | – |
| EN | X6CrNiNb18-10 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Khush Sheets and Plates based in Kolkata, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Stainless steel 347 angles are frequently utilised in corrosive and high-temperature settings, especially in sectors like power generation, chemical processing, aerospace, and petroleum refining. Heat exchangers, boiler tubes, furnace parts, and exhaust manifolds are typical uses. SS 347 is perfect for welded structures exposed to heat because niobium prevents carbide precipitation during welding. Additionally, it is utilised in expansion joints and food processing equipment where thermal cycling takes place. SS 347 Angles are a popular option for structural supports in demanding fabrication and engineering projects because of their superior mechanical qualities and resistance to corrosion.
