Khush Sheets and Plates, located in Delhi, India, stands out as a top manufacturer and supplier of Super Duplex S32760 Circles. These high-performance stainless steel components are specifically designed for the toughest industrial settings. With a strong focus on quality, durability, and meeting international standards, the company provides Super Duplex S32760 Circles that boast remarkable strength, corrosion resistance, and structural integrity. These circles find their place in various sectors, including offshore, marine, chemical, and power generation industries, thanks to their advanced manufacturing techniques. Khush Sheets and Plates has built a reputation for excellence, timely deliveries, and a customer-first approach in both domestic and global markets.
Super Duplex S32760 Circles are made up of 25% chromium, 7% nickel, and 3.6% molybdenum, along with some tungsten, nitrogen, and very little carbon. This well-balanced chemical makeup results in a duplex microstructure that offers outstanding resistance to pitting, crevice corrosion, and chloride stress. They feature a tensile strength of around 800 MPa, a yield strength of 550 MPa, and an elongation of 25%. These characteristics ensure exceptional mechanical performance, toughness, and durability, making them perfect for environments that face aggressive chemicals and high mechanical stress.
| Specifications | ASTM A240 / ASME SA240 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Thickness | 1 mm To 100 mm |
| Diameter | Upto 2000 mm |
| Circle | 3″ DIA up to 38″ DIA 1500 lbs max |
| Rings | 3″ OD up to 48″ OD Up to 900 lbs max |
| Cutting | Plazma & Machined Cut |
| Finish | HR, CR, 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Cold Rolled Circle, Small Flat Circle, Industrial Circle, Perforated Circle, Forged Steel Circles, Cnc Finish Circle, Polished Unique Circle, Hot Rolled Circle, Fey Laminar Rings, Proof Machined Rings, Cold Rolled Rings, Hot Rolled Rings, McInnes Rolled Rings, Die-Formed Rings, Forging Rings, CNC Machined Rings. |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4410 | S32760 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
Khush Sheets and Plates based in Kolkata, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Super Duplex S32760 Circle offers numerous advantages, including exceptional corrosion resistance, particularly in chloride-rich environments, making it ideal for marine, chemical, and offshore applications. Its high strength and excellent mechanical properties, such as high yield and tensile strength, allow it to withstand extreme pressures and temperatures. The alloy’s superior resistance to stress corrosion cracking, pitting, and crevice corrosion enhances its durability in harsh conditions. Additionally, Super Duplex S32760 provides excellent weldability, ensuring strong, reliable joints. These properties make it a preferred choice for industries requiring high-performance materials with long-lasting reliability.
Yes, we offer custom sizes for Super Duplex Steel S32760 Circle to meet specific project needs. Our team at Khush Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Size | 18 G. | 19 G. | 20 G. | 22 G. | 24 G. | 26 G. |
| .4.5 | .0-107 | 0-085 | 0-080 | 0-062 | 0.049 | 0-040 |
| 5 | 0-120 | 0-095 | 0-090 | 0-070 | 0-055 | 0-045 |
| 5.5 | 0-146 | 0-119 | 0-109 | 0-085 | 0-066 | 0-054 |
| 6 | 0-172 | 0-136 | 0-130 | 0-100 | 0-079 | 0-064 |
| 6.5 | 0-200 | 0-153 | 0-150 | 0-128 | 0-093 | 0-074 |
| 7 | 0-235 | 0-190 | 0-176 | 0-136 | 0-107 | 0-088 |
| 7.5 | 0.270 | 0.212 | 0.201 | 0-157 | 0-123 | 0-100 |
| 8 | 0-307 | 0-240 | 0-230 | 0-180 | 0-140 | 0-115 |
| 8.5 | 0-347 | 0-270 | 0-262 | 0-202 | 0-156 | 0-130 |
| 9 | 0-388 | 0-330 | 0-301 | 0-230 | 0-178 | 0-145 |
| 9.5 | 0-472 | 0-342 | 0-324 | 0-252 | 0-198 | 0-162 |
| 10 | 0-480 | 0-380 | 0-360 | 0-280 | 0-220 | 0-180 |
| 11 | 0-580 | 0-450 | 0-435 | 0-338 | 0-266 | 0-218 |
| 12 | 0-690 | 0-540 | 0-518 | 0-403 | 0-318 | 0-253 |
| 13 | 0-811 | 0-640 | 0-508 | 0-608 | 0-371 | 0-304 |
| 14 | 0-940 | 0-750 | 0-708 | 0-558 | 0-430 | 0-352 |
| 15 | 1-080 | 0-860 | 0-808 | 0-650 | 0-495 | 0-405 |
| 16 | 1-228 | 0-960 | 0-921 | 0-736 | 0-563 | 0-460 |
| 17 | 1-382 | 1-080 | 0-940 | 0-809 | 0-635 | 0-560 |
| 18 | 1-595 | 1-200 | 1-116 | 0-907 | 0-712 | 0-683 |
| 19 | 1-732 | 1-350 | 1-300 | 1-010 | 0-794 | 0-750 |
| 20 | 1-920 | 1-400 | 1-340 | 1-120 | 0-880 | 0-785 |
| RAW MATERIAL | MAX. HARDNESS | TEMPERATURE | ABBREVIATIONSMARKER | |
| BRUCELLOSIS | ROCKWELL | |||
| SOFT IRON | 90 | 56 | -60 540 | D |
| LOW CB STEEL | 120 | 68 | -40 540 | S |
| 304SS | 160 | 83 | -250 700b | 304 |
| 304LSS | 150 | 83 | -250 450 | 304L |
| 316SS | 160 | 83 | -200 700b | 316 |
| 316LSS | 150 | 83 | -200 450 | 316L |
| 321SS | 160 | 83 | -200 700b | 321 |
| 347SS | 160 | 83 | -200 700b | 347 |
| 410SS | 170 | 86 | -40 650 | 410 |
| 5Cr-0.5Mo | 130 | -29 650 | ||
| COPPER | 80 | -100 315 | ||
| ALUMINUM | 35 | -200 425 | ||
| INCONEL 600 | 150 | -100 1095 | ||
| INCOLOY 825 | 160 | -100 1095 | ||
| MONEL 400 | 150 | -100 760 | ||
| TITANIUM | 215 | -200 540 | ||
| NICHEL 200 | 110 | -200 760 | ||
| HASTELLOY C276 | 200 | -100 1095 | ||
These Super Duplex S32760 Circles are in high demand across industries that require top-notch strength, corrosion resistance, and reliability. In the oil and gas sector, they are commonly used in pressure vessels, pipe flanges, and subsea components. The marine industry incorporates them into shipbuilding, seawater cooling systems, and offshore platforms. Chemical and petrochemical plants utilize them in reactors, heat exchangers, and storage tanks. Additionally, they play a crucial role in power generation, desalination plants, and paper and pulp processing systems. Their impressive resistance to chlorides, erosion, and stress cracking makes them ideal for challenging environments and critical service conditions.
